Concentrated Maxx power

The Mini Maxx offers performance that others can't match, in a compact, fun shape that's instantly recognizable and uncompromisingly designed for performance and durability. It's a whole new way to experience Maxx fun in a powerful machine that continues the Maxx series' heritage of speed and absolute ruggedness.

Detailed specifications

Performance Maxx

The Traxxas Mini Maxx is equipped with system brushless BL-2Ssystem, already proven to deliver extreme power and phenomenal torque in Traxxas 1/10 scale vehicles. Installed in the Mini Maxx, the BL-2S engine delivers blistering acceleration and a top speed of over 50 km/h.

1/10-scale 4X4 transmission

Robust components Large steel gear differentials, robust 32-pitch gears and universal joint driveshafts.
Extreme durability Extreme durability: Designed to far exceed requirements for strength and longevity.

Maxx chassis technology

Rigid, unified structure Maxx: Maximum impact resistance.
Compact design The Mini Maxx chassis is designed to withstand the toughest conditions while remaining easy to transport.

Clip-free bodywork

Easy installation Simply place the body on the chassis and it locks into place.
Quick access Press the tabs under the wheel arches to access the battery in seconds.

Long-travel suspension

Ultra Shocks™ shock absorbers in 1/10 scale
Long-travel independent suspension
Exceptional handling Maintains control over the roughest terrain thanks to refined damping.

Dimensions

Length length : 345 mm
Front/rear track track : 253 mm
Ground clearance Ground clearance : 27 mm
Weight Weight : 1.64 kg
Height Height : 137 mm
Wheelbase : 220 mm
Shock absorber length : 88 mm
Tire diameter 100 mm
Wheel diameter 66 mm

Technical specifications

Speed control ESC brushless BL-2S waterproof
Motor Motor brushless sensorless BL-2S (3300 Kv)
Transmission Direct drive 4WD
Transmission ratio : 9,20:1
Differential type Steel planetary gear
Gear pitch : 32
Frame Modular tubular composite structure
Radio system : TQ™ 2.4 GHz (2 channels)
Servo : High-torque waterproof servo 2056
Top speed : 50+ km/h
Skill level : 1
Battery compartment dimensions Dimensions : 113 mm (L) x 41 mm (W) x 22 mm (H)
Batteries required 4 "AA" batteries for transmitter

Motor specifications

Type Engine brushless sensorless BL-2S 3300 Kv
Weight : 213 g
Length Length : 80 mm
Diameter Diameter : 36 mm

ESC specifications

Input voltage 6-7 NiMH / 2S LiPo cells
Case dimensions 39 mm x 59 mm x 31 mm
Weight : 87 g
BEC Voltage voltage: 6.0 volts

Main features

Top speed 50+ km/h thanks to brushless BL-2S 3300 Kv motor.
BL-2S waterproof ESC with three programmable drive profiles and integrated low-voltage detection.
LiPo 2S 3500 mAh battery included for long runtime, with 2-amp USB-C charger.
2.4 GHz TQ™ radio system for precise control and extended range.
Clip-free body for fast, secure installation and removal.
Transmission 4WD robust with 1/10 scale components for increased durability.
Modular composite chassis for maximum strength and easy maintenance.
Long-travel suspension with Ultra Shocks™ shock absorbers for exceptional handling.
Sledgehammer® wheels and tires for optimum grip on all terrains.

The Mini Maxx is a monster truck Maxx scale, fully assembled, ready to roll, with TQ™ 2.4 GHz radio system, power system brushless BL-2S™ power system and a clip-free painted body. Includes 2S LiPo battery and 2 amp USB-C charger.

Box contents

Monster truck Mini Maxx ready to roll
Power system brushless BL-2S
2S 3500 mAh LiPo battery
2 amp USB-C charger
Quick start guide
2.4 GHz TQ radio system
High-quality maintenance tools

What you need

AA batteries Four AA alkaline batteries for the transmitter
Charging accessories : 2912 AC adapter and 2916 power cable recommended for easy charging performance optimal charging.

Ready to harness the power of Traxxas Mini Maxx BL-2S ? Don't wait any longer for an intense and fun riding experience with this monster truck compact, ultra-high-performance machine!
